MAX394EUP+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH QUAD SPDT 20TSSOP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX394EUP+T Datasheet
-
ECAD Model
- Share
In Stock: 184
Can ship immediately
Pricing:
- 1$7.605
- 2,500$6.70463
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:4
- On-State Resistance (Max):35Ohm
- Channel-to-Channel Matching (ΔRon):500mOhm
- Voltage - Supply, Single (V+):2.7V ~ 15V
- Voltage - Supply, Dual (V±):±2.7V ~ 8V
- Switch Time (Ton, Toff) (Max):130ns, 75ns
- -3db Bandwidth:-
- Charge Injection:5pC
- Channel Capacitance (CS(off), CD(off)):12pF, 12pF
- Current - Leakage (IS(off)) (Max):200pA
- Crosstalk:-88dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:20-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:20-TSSOP
