DG211DJ+

Technical Details

• Series:-
• Package:Tube
• Part Status:Active
• Switch Circuit:SPST - NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):175Ohm
• Channel-to-Channel Matching (ΔRon):-
• Voltage - Supply, Single (V+):±4.5V ~ 18V
• Voltage - Supply, Dual (V±):±4.5V ~ 18V

• Switch Time (Ton, Toff) (Max):1µs, 500ns
• -3db Bandwidth:-
• Charge Injection:-
• Channel Capacitance (CS(off), CD(off)):5pF, 5pF
• Current - Leakage (IS(off)) (Max):5nA
• Crosstalk:-90dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Through Hole
• Package / Case:16-DIP (0.300", 7.62mm)
• Supplier Device Package:16-PDIP
