MAX4608EPE

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):2.5Ohm
• Channel-to-Channel Matching (ΔRon):50mOhm
• Voltage - Supply, Single (V+):4.5V ~ 36V
• Voltage - Supply, Dual (V±):±4.5V ~ 20V

• Switch Time (Ton, Toff) (Max):110ns, 150ns
• -3db Bandwidth:-
• Charge Injection:45pC
• Channel Capacitance (CS(off), CD(off)):64pF, 64pF
• Current - Leakage (IS(off)) (Max):500pA
• Crosstalk:-66dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Through Hole
• Package / Case:16-DIP (0.300", 7.62mm)
• Supplier Device Package:16-PDIP
