MAX4560EEE+T

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:3
• On-State Resistance (Max):160Ohm
• Channel-to-Channel Matching (ΔRon):2Ohm
• Voltage - Supply, Single (V+):2V ~ 12V
• Voltage - Supply, Dual (V±):±2V ~ 6V

• Switch Time (Ton, Toff) (Max):150ns, 120ns
• -3db Bandwidth:-
• Charge Injection:2.4pC
• Channel Capacitance (CS(off), CD(off)):2pF, 4pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-93dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-SSOP (0.154", 3.90mm Width)
• Supplier Device Package:16-QSOP
