MAX4620ESD+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH QUAD SPST 14SOIC
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4620ESD+T Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):70Ohm
- Channel-to-Channel Matching (ΔRon):500mOhm
- Voltage - Supply, Single (V+):2V ~ 12V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):15ns, 10ns
- -3db Bandwidth:-
- Charge Injection:3pC
- Channel Capacitance (CS(off), CD(off)):5pF, 8.5pF
- Current - Leakage (IS(off)) (Max):1nA
- Crosstalk:-96dB @ 100kHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:14-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:14-SOIC
