MAX4948EBA+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH HEX SPDT 25UCSP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4948EBA+T Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:6
- On-State Resistance (Max):5.5Ohm
- Channel-to-Channel Matching (ΔRon):300mOhm
- Voltage - Supply, Single (V+):1.8V ~ 5.5V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):800ns, 800ns
- -3db Bandwidth:300MHz
- Charge Injection:10pC
- Channel Capacitance (CS(off), CD(off)):15pF
- Current - Leakage (IS(off)) (Max):3nA
- Crosstalk:-90dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:25-WFBGA, CSPBGA
- Supplier Device Package:25-UCSP (5x5)
