STG3384DTR

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):700mOhm
• Channel-to-Channel Matching (ΔRon):600mOhm
• Voltage - Supply, Single (V+):1.65V ~ 4.3V
• Voltage - Supply, Dual (V±):-

• Switch Time (Ton, Toff) (Max):50ns, 30ns
• -3db Bandwidth:85MHz
• Charge Injection:44pC
• Channel Capacitance (CS(off), CD(off)):5pF
• Current - Leakage (IS(off)) (Max):10nA
• Crosstalk:-76dB @ 100kHz
• Operating Temperature:-55°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:10-UFDFN
• Supplier Device Package:10-TDFN (2.5x1.3)
