MAX4592EUE+
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH QUAD SPST 16TSSOP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4592EUE+ Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):20Ohm
- Channel-to-Channel Matching (ΔRon):500mOhm
- Voltage - Supply, Single (V+):3V ~ 16V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):80ns, 45ns
- -3db Bandwidth:-
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):9pF, 9pF
- Current - Leakage (IS(off)) (Max):100pA
- Crosstalk:-85dB @ 10MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
