AS1744G

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:2
• On-State Resistance (Max):4Ohm
• Channel-to-Channel Matching (ΔRon):100mOhm
• Voltage - Supply, Single (V+):1.8V ~ 5.5V
• Voltage - Supply, Dual (V±):-

• Switch Time (Ton, Toff) (Max):17ns, 6ns
• -3db Bandwidth:-
• Charge Injection:7pC
• Channel Capacitance (CS(off), CD(off)):20pF
• Current - Leakage (IS(off)) (Max):100pA
• Crosstalk:-90dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
• Supplier Device Package:10-MSOP
