DG411C/D
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH SPST OCTAL DIE
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet DG411C/D Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Obsolete
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:8:1
- Number of Circuits:8
- On-State Resistance (Max):35Ohm
- Channel-to-Channel Matching (ΔRon):100mOhm
- Voltage - Supply, Single (V+):13V ~ 44V
- Voltage - Supply, Dual (V±):±7V ~ 22V
- Switch Time (Ton, Toff) (Max):175ns, 145ns
- -3db Bandwidth:-
- Charge Injection:5pC
- Channel Capacitance (CS(off), CD(off)):9pF, 9pF
- Current - Leakage (IS(off)) (Max):150nA
- Crosstalk:-85dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:Die
- Supplier Device Package:Die
