MAX399C/D

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• Switch Circuit:SP4T
• Multiplexer/Demultiplexer Circuit:4:1
• Number of Circuits:2
• On-State Resistance (Max):100Ohm
• Channel-to-Channel Matching (ΔRon):6Ohm (Max)
• Voltage - Supply, Single (V+):3V ~ 15V
• Voltage - Supply, Dual (V±):±3V ~ 8V

• Switch Time (Ton, Toff) (Max):150ns, 150ns
• -3db Bandwidth:-
• Charge Injection:2pC
• Channel Capacitance (CS(off), CD(off)):11pF, 20pF
• Current - Leakage (IS(off)) (Max):100pA
• Crosstalk:-92dB @ 100kHz
• Operating Temperature:0°C ~ 70°C
• Mounting Type:Surface Mount
• Package / Case:Die
• Supplier Device Package:Die
