MAX312MJE
Maxim Integrated- Lifecycle status Active
- RoHS RoHS Compliant
- Description10OHM, QUAD, SPST, CMOS ANALOG S
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):9Ohm
- Channel-to-Channel Matching (ΔRon):300mOhm
- Voltage - Supply, Single (V+):4.5V ~ 30V, ±4.5V ~ 20V
- Voltage - Supply, Dual (V±):4.5V ~ 30V, ±4.5V ~ 20V
- Switch Time (Ton, Toff) (Max):225ns, 185ns
- -3db Bandwidth:-
- Charge Injection:20pC
- Channel Capacitance (CS(off), CD(off)):15pF, 15pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-85dB @ 1MHz
- Operating Temperature:-55°C ~ 125°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-CDIP (0.300", 7.62mm)
- Supplier Device Package:16-CERDIP
