MAX4800CCM+

Technical Details

• Series:-
• Package:Tray
• Part Status:Active
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:8
• On-State Resistance (Max):38Ohm
• Channel-to-Channel Matching (ΔRon):1.9Ohm
• Voltage - Supply, Single (V+):2.7V ~ 13.2V
• Voltage - Supply, Dual (V±):2.7V ~ 13.2V

• Switch Time (Ton, Toff) (Max):5µs, 5µs
• -3db Bandwidth:-
• Charge Injection:820pC
• Channel Capacitance (CS(off), CD(off)):11pF
• Current - Leakage (IS(off)) (Max):4µA
• Crosstalk:-80dB @ 5MHz
• Operating Temperature:0°C ~ 70°C (TA)
• Mounting Type:Surface Mount
• Package / Case:48-LQFP
• Supplier Device Package:48-TQFP (7x7)
