- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE ARRAY SCHOTTKY 40V TO247AC
- CategoryDiodes - Rectifiers - Arrays
- Datasheet 30CPQ040 Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
- 1$0.63056
- 3,000$0.63056
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Diode Configuration:1 Pair Common Cathode
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):40 V
- Current - Average Rectified (Io) (per Diode):15A
- Voltage - Forward (Vf) (Max) @ If:540 mV @ 15 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:1.75 mA @ 40 V
- Operating Temperature - Junction:-55°C ~ 150°C
- Mounting Type:Through Hole
- Package / Case:TO-247-3
- Supplier Device Package:TO-247AC
