DAC7742Y/2K
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, PARALLEL, WORD INPUT
- CategoryData Acquisition - Digital to Analog Converters (DAC)
-
ECAD Model
- Share
In Stock: 4,100
Can ship immediately
Pricing:
- 1$11.61
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Number of Bits:16
- Number of D/A Converters:1
- Settling Time:4µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External, Internal
- Voltage - Supply, Analog:±11.4V ~ 15.75V, -4.75V ~ -15.75V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±6 (Max), ±4 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:48-LQFP
- Supplier Device Package:48-LQFP (7x7)
- Mounting Type:Surface Mount
