AD558JP-REEL7
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDACPORT MICROPROCESSOR 8-BIT DAC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD558JP-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 789
Can ship immediately
Pricing:
- 1$13
- 250$13
Quote It
Technical Details
- Series:DACPORT®
- Package:Bulk
- Part Status:Obsolete
- Number of Bits:8
- Number of D/A Converters:1
- Settling Time:3µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:Internal
- Voltage - Supply, Analog:4.5V ~ 16.5V
- Voltage - Supply, Digital:4.5V ~ 16.5V
- INL/DNL (LSB):±0.5 (Max), -
- Architecture:R-2R
- Operating Temperature:0°C ~ 70°C
- Package / Case:20-LCC (J-Lead)
- Supplier Device Package:20-PLCC (9x9)
- Mounting Type:Surface Mount
