AD7248AAR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, PARALLEL, 8 BITS INPUT
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7248AAR Datasheet
-
ECAD Model
- Share
In Stock: 351
Can ship immediately
Pricing:
- 1$13.79
Quote It
Technical Details
- Series:DACPORT®
- Package:Tube
- Part Status:Obsolete
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:7µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:Internal
- Voltage - Supply, Analog:±10.8V ~ 16.5V
- Voltage - Supply, Digital:10.8V ~ 16.5V
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:20-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:20-SOIC
- Mounting Type:Surface Mount
