AD7243BN
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, SERIAL INPUT LOADING
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7243BN Datasheet
-
ECAD Model
- Share
In Stock: 3,766
Can ship immediately
Pricing:
- 1$15.6
Quote It
Technical Details
- Series:DACPORT®
- Package:Tube
- Part Status:Obsolete
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:10µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:SPI
- Reference Type:External, Internal
- Voltage - Supply, Analog:±10.8V ~ 16.5V
- Voltage - Supply, Digital:-
- INL/DNL (LSB):±0.5 (Max), ±0.9 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
- Mounting Type:Through Hole
