AD7840JN
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC,SERIAL, PARALLEL, WORD INPUT
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7840JN Datasheet
-
ECAD Model
- Share
In Stock: 2,384
Can ship immediately
Pricing:
- 1$18.01
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Bits:14
- Number of D/A Converters:1
- Settling Time:4µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel, Serial
- Reference Type:External, Internal
- Voltage - Supply, Analog:±5V
- Voltage - Supply, Digital:-
- INL/DNL (LSB):±2 (Max), ±0.9 (Max)
- Architecture:R-2R
- Operating Temperature:0°C ~ 70°C
- Package / Case:24-DIP (0.300", 7.62mm)
- Supplier Device Package:24-PDIP
- Mounting Type:Through Hole
