AD7537JP
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description2 CH DAC, PARALLEL, 8 BITS INPUT
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7537JP Datasheet
-
ECAD Model
- Share
In Stock: 846
Can ship immediately
Pricing:
- 1$21.32
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Bits:12
- Number of D/A Converters:2
- Settling Time:1.5µs
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:10.8V ~ 16.5V
- Voltage - Supply, Digital:10.8V ~ 16.5V
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:28-LCC (J-Lead)
- Supplier Device Package:28-PLCC (11.51x11.51)
- Mounting Type:Surface Mount
