AD7245ABN
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLC2MOS 12-BIT DACPORT
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7245ABN Datasheet
-
ECAD Model
- Share
In Stock: 476
Can ship immediately
Pricing:
- 1$22.84
- 15$22.84
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:7µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:Internal
- Voltage - Supply, Analog:±10.8V ~ 16.5V
- Voltage - Supply, Digital:±10.8V ~ 16.5V
- INL/DNL (LSB):±0.5LSB (Max), ±1LSB (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:24-DIP (0.300", 7.62mm)
- Supplier Device Package:24-PDIP
- Mounting Type:Through Hole
