AD7545CQ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, 1 FUNC, PARALLEL, WORD INPU
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7545CQ Datasheet
-
ECAD Model
- Share
In Stock: 2,603
Can ship immediately
Pricing:
- 1$25.25
- 18$25.25
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:2µs
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:5V ~ 15V
- Voltage - Supply, Digital:5V ~ 15V
- INL/DNL (LSB):±0.5 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-25°C ~ 85°C
- Package / Case:20-CDIP (0.300", 7.62mm)
- Supplier Device Package:20-CDIP
- Mounting Type:Through Hole
