AD7228ABN
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description8-CH DAC, PARALLEL, 8 BITS INPUT
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7228ABN Datasheet
-
ECAD Model
- Share
In Stock: 381
Can ship immediately
Pricing:
- 1$30.32
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Bits:8
- Number of D/A Converters:8
- Settling Time:5µs, 7µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:10.8V ~ 16.5V, ±5V
- Voltage - Supply, Digital:13.5V ~ 16.5V
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:24-DIP (0.300", 7.62mm)
- Supplier Device Package:24-PDIP
- Mounting Type:Through Hole
