AD7226KP
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, PARALLEL, 8 BITS INPUT
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7226KP Datasheet
-
ECAD Model
- Share
In Stock: 2,259
Can ship immediately
Pricing:
- 1$35.69
- 9$35.69
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Bits:8
- Number of D/A Converters:4
- Settling Time:4µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:11.4V ~ 16.5V, -5V
- Voltage - Supply, Digital:14.25V ~ 15.75V
- INL/DNL (LSB):±0.5 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:20-LCC (J-Lead)
- Supplier Device Package:20-PLCC (9x9)
- Mounting Type:Surface Mount
