AD7225BQ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, 1 FUNC, PARALLEL, 8 BITS IN
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7225BQ Datasheet
-
ECAD Model
- Share
In Stock: 694
Can ship immediately
Pricing:
- 1$40.25
- 15$40.25
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:8
- Number of D/A Converters:4
- Settling Time:4µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:11.4V ~ 16.5V
- Voltage - Supply, Digital:11.4V ~ 16.5V
- INL/DNL (LSB):±1, ±1
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:24-CDIP (0.300", 7.62mm)
- Supplier Device Package:24-CERDIP
- Mounting Type:Through Hole
