AD7846JP
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, PARALLEL, WORD INPUT
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7846JP Datasheet
-
ECAD Model
- Share
In Stock: 3,867
Can ship immediately
Pricing:
- 1$41.76
- 7$41.76
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Bits:16
- Number of D/A Converters:1
- Settling Time:9µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:±11.4V ~ 15.75V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±16 (Max), ±1 (Max)
- Architecture:String DAC
- Operating Temperature:0°C ~ 70°C
- Package / Case:28-LCC (J-Lead)
- Supplier Device Package:28-PLCC (11.51x11.51)
- Mounting Type:Surface Mount
