AD7549JPZ-REEL
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, 1 FUNC, PARALLEL, 4 BITS IN
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7549JPZ-REEL Datasheet
-
ECAD Model
- Share
In Stock: 553
Can ship immediately
Pricing:
- 1$45.5
- 1,000$36.76723
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:2
- Settling Time:1.5µs
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:15V
- Voltage - Supply, Digital:15V
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:20-LCC (J-Lead)
- Supplier Device Package:20-PLCC (9x9)
- Mounting Type:Surface Mount
