AD7845SQ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, 1 FUNC, PARALLEL, WORD INPU
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7845SQ Datasheet
-
ECAD Model
- Share
In Stock: 378
Can ship immediately
Pricing:
- 1$47.85
- 15$47.85
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:5µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:±14.25V ~ 15.75V
- Voltage - Supply, Digital:-
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-55°C ~ 125°C
- Package / Case:24-CDIP (0.300", 7.62mm)
- Supplier Device Package:24-CDIP
- Mounting Type:Through Hole
