AD7549BQ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, 1 FUNC, PARALLEL, 4 BITS IN
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7549BQ Datasheet
-
ECAD Model
- Share
In Stock: 1,999
Can ship immediately
Pricing:
- 1$51.42
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:2
- Settling Time:1.5µs
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:15V
- Voltage - Supply, Digital:15V
- INL/DNL (LSB):±0.5LSB (Max), ±1LSB (Max)
- Architecture:Multiplying DAC
- Operating Temperature:-40°C ~ 85°C
- Package / Case:20-CDIP (0.300", 7.62mm)
- Supplier Device Package:20-CERDIP
- Mounting Type:Through Hole
