AD569AD
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, 1 FUNC, PARALLEL, WORD INPU
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD569AD Datasheet
-
ECAD Model
- Share
In Stock: 470
Can ship immediately
Pricing:
- 1$85.69
- 13$79.52077
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:16
- Number of D/A Converters:1
- Settling Time:6µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:±10.8V ~ 13.2V
- Voltage - Supply, Digital:±10.8V ~ 13.2V
- INL/DNL (LSB):±0.02, ±0.5
- Architecture:Segmented DAC
- Operating Temperature:-25°C ~ 85°C
- Package / Case:28-CDIP (0.605", 15.37mm)
- Supplier Device Package:28-CDIP
- Mounting Type:Through Hole
