AD565ATD/883B
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, 1 FUNC, PARALLEL, WORD INPU
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD565ATD/883B Datasheet
-
ECAD Model
- Share
In Stock: 581
Can ship immediately
Pricing:
- 1$392.48
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:400ns
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External, Internal
- Voltage - Supply, Analog:±11.4V ~ 16.5V
- Voltage - Supply, Digital:±11.4V ~ 16.5V
- INL/DNL (LSB):±0.125, ±0.25
- Architecture:Current Steering
- Operating Temperature:-55°C ~ 125°C
- Package / Case:24-CDIP (0.600", 15.24mm)
- Supplier Device Package:24-CDIP Side Brazed
- Mounting Type:Through Hole
