MAX5824AUP+
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionULTRA-SMALL, OCTAL CHANNEL, 8-/1
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet MAX5824AUP+ Datasheet
-
ECAD Model
- Share
In Stock: 1,006
Can ship immediately
Pricing:
- 1$3.9
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Number of Bits:10
- Number of D/A Converters:8
- Settling Time:2.6µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:I²C
- Reference Type:External, Internal
- Voltage - Supply, Analog:2.7V ~ 5.5V
- Voltage - Supply, Digital:2.7V ~ 5.5V
- INL/DNL (LSB):±0.2, ±0.1
- Architecture:R-2R
- Operating Temperature:-40°C ~ 125°C
- Package / Case:20-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:20-TSSOP
- Mounting Type:Surface Mount
