AD5314BCPZ-REEL7
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAD5314 - 2.5V TO 5.5V, 500UA, QU
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD5314BCPZ-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 13,621
Can ship immediately
Pricing:
- 1$4.93
- 1,500$4.93
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:10
- Number of D/A Converters:4
- Settling Time:9µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:SPI, DSP
- Reference Type:External
- Voltage - Supply, Analog:2.5V ~ 5.5V
- Voltage - Supply, Digital:2.5V ~ 5.5V
- INL/DNL (LSB):±0.5, ±0.05
- Architecture:String DAC
- Operating Temperature:-40°C ~ 105°C
- Package / Case:10-VFDFN Exposed Pad, CSP
- Supplier Device Package:10-LFCSP-WD (3x3)
- Mounting Type:Surface Mount
