AD7845JNZ
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT V-OUT 24DIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7845JNZ Datasheet
-
ECAD Model
- Share
In Stock: 157
Can ship immediately
Pricing:
- 1$22.42
- 15$20.61034
- 105$17.40649
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:5µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:±14.25V ~ 15.75V
- Voltage - Supply, Digital:-
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:0°C ~ 70°C
- Package / Case:24-DIP (0.300", 7.62mm)
- Supplier Device Package:24-PDIP
- Mounting Type:Through Hole
