MAX525AEAP+
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT V-OUT 20SSOP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet MAX525AEAP+ Datasheet
-
ECAD Model
- Share
In Stock: 691,850
Can ship immediately
Pricing:
- 1$28.66
- 10$27.48208
- 50$27.0487
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:4
- Settling Time:12µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:SPI
- Reference Type:External
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±0.25, ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:20-SSOP (0.209", 5.30mm Width)
- Supplier Device Package:20-SSOP
- Mounting Type:Surface Mount
