AD7548JNZ
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT A-OUT 20DIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7548JNZ Datasheet
-
ECAD Model
- Share
In Stock: 278
Can ship immediately
Pricing:
- 1$35.25
- 18$32.51296
- 36$31.05137
- 108$27.76358
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:1.5µs (Typ)
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:5V, 11.4V ~ 15.75V
- Voltage - Supply, Digital:5V, 11.4V ~ 15.75V
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:0°C ~ 70°C
- Package / Case:20-DIP (0.300", 7.62mm)
- Supplier Device Package:20-PDIP
- Mounting Type:Through Hole
