AD7543JNZ
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT A-OUT 16DIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7543JNZ Datasheet
-
ECAD Model
- Share
In Stock: 204
Can ship immediately
Pricing:
- 1$38.97
- 25$34.32817
- 100$30.69323
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:2µs
- Output Type:Current - Unbuffered
- Differential Output:Yes
- Data Interface:Serial
- Reference Type:External
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±1 (Max), ±2 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
- Mounting Type:Through Hole
