AD9122SCPZ-EP
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 16BIT A-OUT 72LFCSP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD9122SCPZ-EP Datasheet
-
ECAD Model
- Share
In Stock: 170
Can ship immediately
Pricing:
- 1$71.88
- 10$68.28232
Quote It
Technical Details
- Series:TxDAC+®
- Package:Tray
- Part Status:Active
- Number of Bits:16
- Number of D/A Converters:2
- Settling Time:20ns (Typ)
- Output Type:Current - Unbuffered
- Differential Output:Yes
- Data Interface:LVDS - Parallel
- Reference Type:External, Internal
- Voltage - Supply, Analog:3.13V ~ 3.47V
- Voltage - Supply, Digital:1.71V ~ 1.89V
- INL/DNL (LSB):±3.7, ±2.1
- Architecture:Current Source
- Operating Temperature:-55°C ~ 105°C
- Package / Case:72-VFQFN Exposed Pad, CSP
- Supplier Device Package:72-LFCSP-VQ (10x10)
- Mounting Type:Surface Mount
