- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 16BIT V/A-OUT 16DIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD766JNZ Datasheet
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$40.06
- 10$36.94328
- 25$35.28224
- 100$31.54665
Quote It
Technical Details
- Series:DACPORT®
- Package:Tube
- Part Status:Active
- Number of Bits:16
- Number of D/A Converters:1
- Settling Time:1.5µs (Typ)
- Output Type:Voltage - Buffered, Current - Unbuffered
- Differential Output:No
- Data Interface:SPI, DSP
- Reference Type:Internal
- Voltage - Supply, Analog:±4.75V ~ 13.2V
- Voltage - Supply, Digital:±4.75V ~ 13.2V
- INL/DNL (LSB):-
- Architecture:Current Steering
- Operating Temperature:0°C ~ 70°C
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
- Mounting Type:Through Hole
