AD7835APZ
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 14BIT V-OUT 44PLCC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7835APZ Datasheet
-
ECAD Model
- Share
In Stock: 242
Can ship immediately
Pricing:
- 1$60.53
- 27$55.02486
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:14
- Number of D/A Converters:4
- Settling Time:10µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:±11.4V ~ 15.75V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±2 (Max), ±0.9 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:44-LCC (J-Lead)
- Supplier Device Package:44-PLCC (16.59x16.59)
- Mounting Type:Surface Mount
