AD5535ABCZ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description32-CHANNEL, 14-BIT DAC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD5535ABCZ Datasheet
-
ECAD Model
- Share
In Stock: 129
Can ship immediately
Pricing:
- 1$215.87
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Obsolete
- Number of Bits:14
- Number of D/A Converters:32
- Settling Time:65µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:SPI, DSP
- Reference Type:External
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:2.7V ~ 5.25V
- INL/DNL (LSB):±0.1, ±0.5
- Architecture:String DAC
- Operating Temperature:-10°C ~ 85°C
- Package / Case:124-LBGA, CSPBGA
- Supplier Device Package:124-CSPBGA (15x15)
- Mounting Type:Surface Mount
