AD7945BRSZ-REEL
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT A-OUT 20SSOP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7945BRSZ-REEL Datasheet
-
ECAD Model
- Share
In Stock: 178
Can ship immediately
Pricing:
- 1$11.55
- 1,500$6.5161
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:600µs (Typ)
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±0.5 (Max), ±0.5 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:20-SSOP (0.209", 5.30mm Width)
- Supplier Device Package:20-SSOP
- Mounting Type:Surface Mount
