AD5543BRMZ-REEL7
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 16BIT A-OUT 8MSOP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD5543BRMZ-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 181
Can ship immediately
Pricing:
- 1$20.43
- 1,000$13.06703
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Number of Bits:16
- Number of D/A Converters:1
- Settling Time:500ns (Typ)
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:SPI
- Reference Type:External
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±2 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package:8-MSOP
- Mounting Type:Surface Mount
