AD8522ANZ
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT V-OUT 14DIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD8522ANZ Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$35.02
- 25$30.84125
- 100$27.57581
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:2
- Settling Time:16µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:SPI
- Reference Type:Internal
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±0.5, ±0.5
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:14-DIP (0.300", 7.62mm)
- Supplier Device Package:14-PDIP
- Mounting Type:Through Hole
