MAX5156BCPE
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDUAL, 12-BIT, VOLTAGE-OUT DAC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
-
ECAD Model
- Share
In Stock: 137
Can ship immediately
Pricing:
- 1$10.19
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Bits:12
- Number of D/A Converters:2
- Settling Time:15µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:SPI
- Reference Type:External
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:0°C ~ 70°C
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
- Mounting Type:Through Hole
