MAX505BEAG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description8-BIT DAC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
- 1$12.62
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Bits:8
- Number of D/A Converters:4
- Settling Time:6µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:±5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):-, ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:24-SSOP (0.209", 5.30mm Width)
- Supplier Device Package:24-SSOP
- Mounting Type:Surface Mount
