AD5781BRUZ
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 18BIT V-OUT 20TSSOP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD5781BRUZ Datasheet
-
ECAD Model
- Share
In Stock: 197
Can ship immediately
Pricing:
- 1$50.26
- 75$44.92637
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:18
- Number of D/A Converters:1
- Settling Time:1µs (Typ)
- Output Type:Voltage - Unbuffered
- Differential Output:No
- Data Interface:SPI, DSP
- Reference Type:External
- Voltage - Supply, Analog:7.5V ~ 16.5V, -2.5V ~ 16.5V
- Voltage - Supply, Digital:2.7V ~ 5.5V
- INL/DNL (LSB):±0.5, ±0.5
- Architecture:R-2R
- Operating Temperature:-40°C ~ 125°C
- Package / Case:20-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:20-TSSOP
- Mounting Type:Surface Mount
