TLC7528IDWR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 8BIT A-OUT 20SOIC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$2.78556
- 2,000$2.73054
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Number of Bits:8
- Number of D/A Converters:2
- Settling Time:100ns
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:5V ~ 15V
- Voltage - Supply, Digital:5V ~ 15V
- INL/DNL (LSB):±0.5 (Max), ±0.5 (Max)
- Architecture:R-2R
- Operating Temperature:-25°C ~ 85°C
- Package / Case:20-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:20-SOIC
- Mounting Type:Surface Mount
