TLC7524IPWG4
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 8BIT A-OUT 16TSSOP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$3.5635
- 180$3.54347
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:8
- Number of D/A Converters:1
- Settling Time:100ns
- Output Type:Current - Unbuffered
- Differential Output:Yes
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:5V, 14.5V ~ 15.5V
- Voltage - Supply, Digital:5V, 14.5V ~ 15.5V
- INL/DNL (LSB):±0.5 (Max), ±2.5 (Max)
- Architecture:R-2R
- Operating Temperature:-25°C ~ 85°C
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
- Mounting Type:Surface Mount
