DAC7821IPWG4
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT A-OUT 20TSSOP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$5.18114
- 140$5.11787
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:200ns
- Output Type:Current - Unbuffered
- Differential Output:Yes
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:2.7V ~ 5.5V
- Voltage - Supply, Digital:2.7V ~ 5.5V
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 125°C
- Package / Case:20-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:20-TSSOP
- Mounting Type:Surface Mount
